Wireless HDMI Extender Transmitter Dongle & Receiver @1080P up to 100 Feet (WHD-PRO100-K)

Name: Wireless HDMI Extender Transmitter Dongle & Receiver @1080P up to 100 Feet (WHD-PRO100-K)
Brand: OREI
SKU: WHD-PRO100-K
Price: 179.99 USD
Availability: InStock

$179.99 $199.99

Shipping calculated at checkout.

SKU: WHD-PRO100-K

Supports 1080p up to 100 feet line of sight long distance transmission
Less than 300ms latency
HDCP compliant

Overnight shipping*:

Two days shipping:

*Overnight shipping doesn't include Weekends, or any holidays.

Quantity

Reseller & Installer Discounts

Add to Wishlist

30 Days Return

1 Year Warranty

Free shipping in USA

More Details

OREI WHD-PRO100-K: Wireless HDMI Extender Upto 100 Ft

Extend full HD 1080p signal up to 100 feet wirelessly. Will not transmit through walls, direct signal only. Using Channel 128 & 132 on a 5 GHz wireless band
Connect the transmitter to an HDMI camera and the receiver to an HDMI monitor, power the transmitter with a Micro USB cable to the laptop or even a power bank.
Support point to point wireless Connection, support: HDMI 480i 60Hz, 480p 60Hz, 576i 60Hz, 576 50Hz, 720p 50/60Hz, 1080i 50/60Hz, 1080p 50/60Hz, 20
Plug & play setup without any software installation.
Includes: 1 x transmitter, 1 x receiver, 1 x power adapter, 1 x user manual. 1 Year Orei Manufacturer's warranty

AUDIO AND VIDEO

Transmitter:	INPUT PORTS:	HDMI Input Type A [19-pin Male]
Receiver:	OUTPUT PORTS:	HDMI output Type A[19-pin Female]

COMPLIANCES

HDMI Compliance	HDMI 1.3a
HDCP Compliance	HDCP 2

EXTENDING DISTANCE

1080p@60Hz:

30M/100 feet(L.O.S)

VIDEO OUTPUT

Video Bandwidth:	148.5MHZ
Video Resolutions:	1080P/60Hz
Color Space:	RGB/YUV4:4:4
Color Depth:	8bit

LOOP-OUT/LOCAL PORT

Has loop out port:

AUDIO OUTPUT

HDMI Audio Formats:

PCM2.1/Dolby5.1

SIGNALS

TMDS Signals:	Yes
DDC Signals:	Yes

WIRELESS PERFORMANCE & INTERFACE

Transmission Type:	WiFi
Transfer Method:	802.11 a/b/g/n
Latency:	Max. 0.3 sec. latency
Transmission Distance:	30M/ 100 feet (L.O.S)
Maximun Pixel Clock:	12M(H.264)

DIMENSIONS & WEIGHT

Transmitter:	Height:	15.5mm
	Width:	38mm
	Depth:	85.5mm
	Weight:	40 gw
Receiver:	Height:	13.8mm
	Width:	85mm
	Depth:	83mm
	Weight:	65 gw

PROTECTION

Operation Temperature:	0~45℃
Storage temperature:	-10~60℃
Relative Humidity:	10%~80%
ESD Protection:	4K/8K
Electrostatic Protection of the whole Machine:	OVP/OCP

POWER

Power Consumption (Max):	Transmitter:	5W
	Receiver:	5W
Power Supply	Input:	100~240V
	Output:	5V 1A

PHYSICAL PROPERTIES

Color:	Black
Housing:	Plastic
Finishing:	Matte

PACKAGE CONTENTS

1x HDMI Transmitter

1x HDMI Receiver

1x Type A USB to Micro USB power cable (Y type model)

1x DC 5V/1A power adaptor (Micro USB type)

1x User Manual

WARRANTY

1-Year Manufacturer's Warranty

Quick Setup & Installation guide

WHD-PRO100-K User Manual Download

FAQs

Please try the following steps to resolve your pixelating issue:

- Please try replacing your current HDMI cables with High-Quality HDMI cables.

- Please make sure that you dont have any other wireless devices such as wifi router nearby this extender. If you have a wifi router, then please try moving the router away as the wireless signals interfears with each other & causing this issue.

Our all the extenders supports IR Frequency & the devices using RF frequency will not be compatible with our products.

The IR Blaster/Emitter should be connected to the IR out port on the Transmitter and the IR Receiver should be connected to the IR in on the Receiver.

Here's a quick overview of the IR connection on our extenders: IR Blaster Explained | Use IR with HDMI Extender Kit - Remote Control
