4x2 HDMI Matrix with Audio Extraction (BK-402A)


$129.99 $159.99
Shipping calculated at checkout.
SKU: BK-402A

  • Seamless switching of 4 input sources to up to 2 Outputs
  • With video resolutions up to 8K@60Hz 4:2:0 12bit or 4K@120Hz 4:4:4 12bit
  • Audio extraction through S/PDIF and L/R audio output

Overnight shipping*:
Two days shipping:

*Overnight shipping doesn't include Weekends, or any holidays.

Minus Plus
Reseller & Installer Discounts
Add to Wishlist
30 Days Return
30 Days Return
1 Year Warranty
1 Year Warranty
No-Contact Delivery
Free shipping in USA
More Details Right

BK-402A: 40Gbps 4x2 HDMI Matrix with Audio  Extraction

Key Features:

    • HDMI 2.1 & HDCP 2.3 Compliant
    • 40Gbps Video Bandwidth
    • Video resolutions up to 8K@60Hz 4:2:0 10bit
    • Also supports 8K@30Hz 4:4:4 10bit, 4K@120Hz 4:4:4 10bit
    • VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), FVA (Fast VActive) Support
    • eARC support between Input 1 and Output 1
    • Audio Extraction through Optical and Analog 3.5mm ports
    • 8K to 4K and 8K/4K to 2K Downscale support

    The BK-402A 4x2 Matrix is the perfect AV distribution solution to take multiple inputs to 2 outputs. The device features 4 HDMI Inputs and 2 HDMI Outputs. It can take 4 media sources and allow you to display them on 2 outputs at the same time with the option to have different media on different outputs at resolutions up to 8K@60Hz. The device features advanced EDID management through the dip switches on the front. Features Optical and Analog 3.5mm ports for audio extraction. Supports eARC between Input 1 and Output 1. Among other features, the device can also downscale from 8K to 4K and 8K/4K to 2K. The BK-402A Matrix is the best device for various applications in home theatre, educational, or professional setups.
